Description

Dell PowerEdge R660xs
The Dell PowerEdge R660xs
offers compelling performance in
a purpose-built system with the
latest PCIe Gen 5 bandwidth and
storage to support:
? Virtualization / Cloud
? Scale-Out Database
? High Performance Compute

Buy the performance and density you need
The new Dell PowerEdge R660xs is a 1U, two-socket rack server. Buy the best fit in dense performance with this
purpose-built 1U system. Focused on delivering the latest technology to power the most popular applications and
workloads used by businesses today, including virtualization, scale out-database and high performance compute.
All delivered in a thoughtfully crafted platform that will provide dense compute that fits in your current infrastructure.
Easily configurable
? Add up to two 5th generation Intel? Xeon? Scalable processors with up to 28 cores and 4th generation Intel?
Xeon? Scalable processors with up to 32 cores per socket for faster performance
? Accelerate in-memory workloads with up to 16 DDR5 RDIMMS up to 5200 MT/sec
? Improve data throughput and reduce latency with support up to 5 I/O devices (up to 3 PCIe slots, 1 OCP 3.0
networking slot, and 1 dedicated PERC slot)
? Storage options include up to 4x 3.5?? HDDs/SSDs; or up to 10x 2.5?? HDDs/SSDs/NVMe

PowerEdge R660xs Specification

PowerEdge R660xs Specification
Processor	Up to 2 x 5th generation Intel^??Xeon^??Scalable processors with up to 28 cores and 4th generation Intel^??Xeon^??Scalable processors with up to 32 cores per processor.
Operating System	Microsoft^??Windows Server^??with Hyper-V RedHat^??Enterprise Linux SUSE^??Linux Enterprise Server VMware^??vSAN/ESXi^? Canonical^??Ubuntu^??Server LTS
Memory (RAM)	DIMM Speed Up to 5200 MT/s Memory Type RDIMM Memory Module Slots 16 DDR5 DIMM slots Maximum RAM 1.5 TB
Storage	Front Bay Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 96 TB Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153.6 TB Rear Bay Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 15.2 TB Up to 2 x E3.S (Gen5 x NVMe) max 25.6 TB
Storage Controllers	Internal Controllers PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i,?HBA465i External Controllers HBA355e Software RAID S160 Internal Boot Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 1, 2 x M.2 NVMe SSDs (cold swap) USB
Power Supplies	Power Supplies 1800 W Titanium 200??240 VAC or 240 HVDC, hot swap redundant 1400 W Titanium 100??240 VAC or 240 VDC, hot swap redundant 1400 W Platinum 100??240 VAC or 240 HVDC, hot swap redundant 1100 W Titanium 100??240 VAC or 240 HVDC, hot swap redundant 1100 W LVDC -48 ?? (-60) VDC, hot swap redundant 800 W Platinum 100??240 VAC or 240 HVDC, hot swap redundant 700 W Titanium 200??240 VAC or 240 HVDC, hot swap redundant 600 W Platinum 100??240 VAC or 240 HVDC, hot swap redundant Fans Standard (STD) fans, High performance SLVR fans or High performance GOLD fans Up to 7 hot swappable fans
Ports	Network Options 2 x 1GbE LOM card (optional) 1 x OCP card 3.0 (optional) Note: The system allows either LOM card or an OCP card can be installed in the system. Front Ports 1 x iDRAC Direct (Micro-AB USB) port 1 x USB 2.0 1 x VGA Rear Ports 1 x Dedicated iDRAC Ethernet port 1 x USB 2.0 1 x USB 3.0 1 x Serial (optional) 1 x VGA Internal Ports 1 x USB 3.0 (optional)
Slots	PCIe 1 CPU Configuration: Up to 2 PCIe slots (1 x16 Gen4 + 1 x8 Gen5) 2 CPU configuration: Up to 3 PCIe Gen4 slots (1 x16 Gen4 + 2 x8 Gen4)? or up to 2 PCIe Gen5 slots (1 x16 Gen5 + 1 x8 Gen5) Video 1 x VGA
Bezel	Optional LCD bezel or security bezel
Form Factor	1U rack server
Dimensions and Weight	Height 1.68 inches (42.8 mm) Width 18.97 inches (482 mm) Depth 28.05 inches (712.95 mm) without bezel 29.85 inches (748.79 mm) with bezel Weight 55.33 lbs (19.45 Kg)
Rack Support	ReadyRails^??II sliding rails with optional cable management arm (CMA) and strain relief bar (SRB) for 4-post racks Combo (Drop-in/Slide-in) rails with optional CMA and SRB for 4-post racks ReadyRails static rails for 4-post and 2-post racks
