Name: Dell PowerEdge R760 2-Way 2U 12-Bay 3.5-inch 16th Generation Rack Server
Brand: HPEServers PH
SKU: 1944
Availability: InStock
Rating: 5 (1 reviews)

Description

Dell PowerEdge R760
The Dell PowerEdge R760 offers
powerful performance in a purposebuilt, cyber resilient, mainstream server.
Ideal for:
? Mixed Workload Standardization
? Database and Analytics
? Virtual Desktop InfrastructureMax Performance
? Add up to two 4th Generation Intel Xeon Scalable or Intel Xeon Max processors with up to 56 cores or two
5th Generation Intel Xeon Scalable processors with up to 64 cores for faster and more accurate processing
performance.
? Accelerate in-memory workloads with up to 32 DDR5 RDIMMS up to 4800 MT/sec for 1DPC when using 4th Gen
Intel Xeon Scalable processors of 32 DDR5 RDIMMS up to 5600 MT/sec for 1DPC when using 5th Gen Intel Xeon
Scalable processors.
? Support for GPUs including 2 x double-wide or 6 x single-wide for workloads requiring acceleration.

Air cooled at peak performance
? New Smart Flow chassis optimizes airflow to support the highest core count CPUs in an air-cooled environment
within the current IT infrastructure.
? Support for up to 16 x 2.5?? drives and 2 x 350 watt processors.

PowerEdge R760 Specification

PowerEdge R760 Specification
Processor	Up to 2 x 5th Generation Intel? Xeon Scalable processors with up to 64 cores per processor
Operating System	Canonical Ubuntu Server LTS Microsoft Windows Server with Hyper-V RedHat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi
Memory (RAM)	DIMM Speed Up to 5600 MT/s on the 5th Generation Intel? Xeon Scalable processorsMemory Type RDIMMMemory Module Slots 32 DDR5 DIMM slots Maximum RAM RDIMM 8 TB
Storage	Front Bay Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 240 TB Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) max 122.88 TB Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.64 TBMid Bay N/A Rear Bay Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB Up to 4 x EDSFF E3.S Gen5 NVMe (SSD) max 30.72 TB
Storage Controllers	Internal Controllers PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355iExternal Controllers HBA355e,?PERC H965e Software RAID S160 Internal Boot Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs USB
Power Supplies	Power Supplies 3200 W Titanium 277 VAC or 336 HVDC, hot swap redundant 2800 W Titanium 200??240 HLAC or 240 HVDC, hot swap redundant 2400 W Platinum 100??240 VAC or 240 HVDC, hot swap redundant 1800 W Titanium 200??240 HLAC or 240 HVDC, hot swap redundant 1400 W Platinum 100??240 VAC or 240 HVDC, hot swap redundant 1400 W Titanium 277 VAC or 336 HVDC, hot swap redundant 1100 W Titanium 100??240 VAC or 240 HVDC, hot swap redundant 1100 W -(48??60) VDC, hot swap redundant 800 W Platinum 100??240 VAC or 240 HVDC, hot swap redundant 700 W Titanium 200??240 HLAC or 240 HVDC, hot swap redundant
Ports	Network Options 2 x 1GbE LOM card (optional) 1 x OCP card 3.0 (optional) Note: The system allows either LOM card or an OCP card or both to be installed in the system.Front Ports 1 x iDRAC Direct (Micro-AB USB) port 1 x USB 2.0 1 x VGA Rear Ports 1 x Dedicated iDRAC Ethernet port 1 x USB 2.0 1 x USB 3.0 1 x Serial (optional) 1 x VGA (optional for Direct Liquid Cooling configuration) Internal Ports 1 x USB 3.0 (optional)
Slots	PCIe 8 PCIe slots: Slot 1: 1 x8 Gen5 or 1 x8/1 x16 Gen4 Full height, Half length or 1 x16 Gen4 Full height, Full length Slot 2: 1 x8/1 x16 Gen5 or 1 x8 Gen4 Full height, Half length or 1 x16 Gen5 Full height, Full length Slot 3: 1 x16 Gen4 Low profile, Half length Slot 4: 1 x8 Gen4 Full height, Half length Slot 5: 1 x8/1 x16 Gen4 Full height, Half length or 1 x16 Gen4 Full height, Full length Slot 6: 1 x8/1 x16 Gen4 Low Profile, Half length Slot 7: 1 x8/1 x16 Gen5 or 1 x8 Gen4 Full height, Half length or 1 x16 Gen5 Full height, Full length Slot 7 SNAPI: 1 x16 Gen5 Full height, Half length Slot 8: 1 x8 Gen5 or 1 x8 Gen4 Full height, Half lengthVideo 1 x VGA
Bezel	Optional LCD bezel or security bezel
Form Factor	2U rack server
Dimensions and Weight	Height 3.41 inches (86.8 mm)Width 18.97 inches (482 mm) Depth 30.39 inches (772.13 mm) with bezel 29.85 inches (758.29 mm) without bezel Weight Max 79.58 lbs. (36.1 kg)
Rack Support	ReadyRails? II sliding rails with optional cable management arm (CMA) and strain relief bar (SRB) for 4-post racks Combo (Drop-in/Slide-in) rails with optional CMA and SRB for 4-post racks ReadyRails static rails for 4-post and 2-post racks Note: CMA is not supported in Direct Liquid Cooling configuration ?
